ApolloX™

ApolloX is a professional high-performance engineering filament, which is based on an uniquely industrial-grade modified ASA (Acrylonitrile Styrene Acrylate) compound. ApolloX has been modified to have great thermal stability, improved filament flowing behavior, zero-warping and flawless first- and interlayer adhesion allowing you to 3D print objects with an almost injection-molded precision. ApolloX is UV and weather resistant and by that ensuring great color stability – combined with high strength and heat resistant properties – which makes ApolloX™ a perfect engineering filament for outdoor and automotive applications.

Unique features

  • FDM/FFF-optimized
    • Warp-free printing
    • Optimized filament flowing behaviour, thermal stability, and inter-layer adhesion
    • Excellent adhesion to heated glass plate, Kapton tape, PET tape and Formfutura EasyPad
  • Greatly improved mechanical properties and strength
  • UV weather resistant
  • Extremely high printing precision
    • Printing with remarkable fine detail
  • Engineered to be compliant to FDA food and drink contact articles

General printing guidelines *

Nozzle size: ≥ 0.15mm

Layer height: ≥ 0.1mm

Flow rate: ± 100%

Print temp: ± 235 - 255° C

Print speed: Medium

Retraction: Yes - 5mm

Heat bed: ± 80 - 90° C

Fan speed: 0-25%

Experience level: Beginner / Intermediate

 *) Above displayed settings are meant as guidance to find your optimal print settings. These ranges in settings should work for most printers, but please do feel free to experiment outside these ranges if you think it is suitable for your printer. There are a lot of different type of printers, hot-ends and printer offsets that it is extremely difficult to give an overall one-size-fits-all setting.

Filament length

ρ: 1.11 g/cc

50 gr coil

0.75 Kg spool

2.3 Kg spool

4.5 Kg spool

8 Kg spool

Ø 1.75mm

± 18.7m

± 281m

± 861m

± 1685m

± 2996m

Ø 2.85mm

± 7.1m

± 106m

± 325m

± 635m

± 1130m

Product export information

HS Code: 39169090

Description: Monofilament

Country of origin: the Netherlands

*) FDA compliant filament is specifically made of FDA compliant polymers for direct food contact/containers or raw plastic material for 3D Printing Prototyping and Manufacturing. This filament is made to meet the requirements for the use in Food Contact Articles. Please note that the filaments do not have an actual FDA listing number.

*) RoHS REACH compliance in accordance with: RoHS Directive 2011/65/EC -- REACH Directive 1907/2006/EC.

(V177-285APOX-WHITE-0750)

SKU V177-285APOX-WHITE-0750
Barcode # 8718924476307
Shipping Weight 1.0500kg
Shipping Width 0.210m
Shipping Height 0.065m
Shipping Length 0.205m
Shipping Cubic 0.002798250m3
Unit Of Measure Carton
